| Use: | Faster, economical and simple method to connect valve to existing or new lines under pressure. |
| MJ Outlet: | Type 304 (18-8) Stainless Steel per ASTM A743 and ANSI/AWWA C111. Or Carbon Steel. Solid One-Piece casting |
| Panel: | Type 304 (18-8) Stainless Steel per ASTM A240. |
| Shell Gasket: | SBR Chek-O-Seal with multi o-ring sealing ribs from 100% new rubber to ensure performance under varying pressures with superior storage characteristics. Suitable for mild acids, water and salt media with a temperature range of -40 °F to +200 °F per ASTM D2000. Other materials are available. |
| Branch Gasket: | NBR per ASTM D2000 with Hydro TwinSeal® dual o-ring design incorporating both hydro-static and mechanical forces to affect a dynamic seal. |
| Bolts & Nuts: | Type 304 (18-8) Stainless Steel per ASTM A193 and A194 for sleeves with Stainless MJ and Low Alloy Steel Bolts and Nuts per ASTM A325 and ASTM A563 for sleeves with Carbon Steel MJ. NOTE: Stainless Steel hex nuts are furnished with fusion bonded coating to prevent seizing and galling. |
| Washer: | Stainless Steel per ASTM A240 |
